Experience the epitome of modern sophistication with Edilians’ Slate Panne S tile. Merging timeless elegance with contemporary design, sleek and sophisticated, these tiles are setting a new standard for style in roofing solutions.
| Quantity per pallet | 420 tiles |
|---|---|
| Coverage | 20 per m2 |
| Nominal gauge | 275mm |
| Overall length | 342mm |
| Overall width | 232mm |
| Working width | 190mm |
| Minimum headlap | 67mm |
| Unit weight | 2.3Kg |
| Weight per m2 | 46Kg |
| Minimum roof pitch | 22.5° |
| Batten coverage m2 | 3.64 l/m |
| Batten sizes | 38 x 25mm rafter centres 450mm 50 x 25mm rafter centres 600mm |
| Nail size | 50 x 3.35mm |
Crafted with precision and durability in mind, these tiles are not only aesthetically pleasing to the eye, but also provide long-lasting performance.
No information to display, please contact us if you have any additional questions.
Fill out the form below to request a physical brochure.
