Our elegant and charming Old Vintage colourway by Edilians is a stunning rendition of the classic clay tile, meticulously crafted to enhance and harmonise with traditional roofscapes. Inspired by the enduring popularity of the Old English Pantile, this timeless design pays homage to centuries of architectural heritage.
| Quantity per pallet | 420 tiles |
|---|---|
| Coverage | 20 per m2 |
| Nominal gauge | 275mm |
| Overall length | 342mm |
| Overall width | 232mm |
| Working width | 190mm |
| Minimum headlap | 67mm |
| Unit weight | 2.3Kg |
| Weight per m2 | 46Kg |
| Minimum roof pitch | 22.5° |
| Batten coverage m2 | 3.64 l/m |
| Batten sizes | 38 x 25mm rafter centres 450mm 50 x 25mm rafter centres 600mm |
| Nail size | 50 x 3.35mm |
