Edilians Phalempin Clay Tiles in Amber are the perfect way to add warmth and character to a project. Crafted from natural clay in the heart of France, these tiles boast a rich, warm hue that beautifully complements a variety of architectural styles. Their classic design, inspired by centuries-old techniques, adds a touch of sophistication to both new builds and restoration projects.
| Quantity per pallets | 1088 tiles |
|---|---|
| Coverage | 60 per m2 |
| Nominal gauge | 100mm |
| Overall length | 268mm |
| Overall width | 168mm |
| Working width | 168mm |
| Minimum headlap | 68mm |
| Unit weight | 1.1kg |
| Weight per m2 | 64.9kg |
| Minimum roof pitch | 30° |
| Batten coverage m2 | 10 l/m |
| Batten sizes | 38 x 25mm rafter centres 450mm 38 x 25mm rafter centres 600mm |
| Nail size | 38/40 x 2.65mm |
Key features:
The quality of tiles and accessories produced at Phalempin is unquestionable; The factory is certified to ISO 9001 and 14001 and all products achieve the highest frost resistance rating; 150 freeze/thaw cycles, when tested under European Standard EN 539-2: Test for frost resistance; a prerequisite for clay tiles produced for use in the UK. All Phalempin clay tiles fully comply with the requirements of BS EN 1304: the European Standard for clay roof tiles and can be expected to last more than 100 years.
The Phalempin Plain tile range is one of the few double-lapped plain tiles on the UK market that can be used on roof pitches as low as 30 degrees. Although the British Standard for Slating and Tiling; BS 5534, recommends a minimum roof pitch of 35 degrees for double-lapped plain tiles, the method of manufacture enables unique anti-capillary channels to be incorporated onto the Phalempin tiles’ upper surface, ensuring enhanced performance. Wind-driven rain testing carried out independently by BRE has enabled certification of the tiles for use at 30 degrees.
