The Holkham Barn tile is a handcrafted clay pantile with a flatter and slightly wider profile than the Ashvale, more typical of the traditional tile found in Norfolk. It has the appearance of a reclaimed Barn tile, but with all the advantages of availability, quality and price attributed to new tiles.
| DESCRIPTION | ROOF |
|---|---|
| Minimum roof pitch | 30Ëš |
| Batten spacing | 285mm |
| Size of tile | 360 x 250mm |
| Covering capacity | 16.7 tiles per m² |
| Cover width | 210mm |
| Profile depth | 35mm |
| Hanging length | 340mm |
| Weight as laid | 41.75 kg per m² |
| Gross Weight per | 0.98 tonnes |
| Quantity per pallet | 320 |
| Battens per m² | 3.5m |
| Batten size | 50 x 25mm |
| Nail size/ type for tiles | 50 x 3.35mm alloy clout |
All tiles comply with C E Marking to British and European Standard BS EN 1304, which legislates for externally tested and verified quality of roof tiles. The tiles are independently tested to the following standards by Lucideon (approved by UKAS and the British Standards Institute):
Determination of Impermeability : BSEN 539-1:2005 Method 2 & BSEN 1304:2005
Determination of Flexural Strength : BSEN 538:1994
Determination of Frost Resistance : BSEN 539-2:2013
The Ashvale and Holkham Barn clay pantiles can both be used on roofs pitched to 30Ëš assuming they are fixed in accordance with the British Standard Code of Practice for Slating & Tiling BS 5534: 2014.
However, if your roof pitch is lower than 30Ëš, please contact us with details of your requirements and we can offer a clay pantile solution down to a pitch as low as 17.5Ëš from our French Collection.
Both tiles are suitable for use in any part of the country, but indigenously pantiles are more commonly found in East Anglia and up the East coast of England.
